▶ 제품사양
<모바일 이용 시 좌우로 슬라이드해서 보세요>
제품 종류 | SOM-2569CNCCA-S7A1 | SOM-2569BNBCA-S7A1 | SOM-2569BNBC-S7A1 | SOM-2569BNBC-S6A1 | SOM-2569BN0C-S3A1 | SOM-2569CNCCA-S2A1 | SOM-2569BCBC-S1A1 | |
폼 팩터 | 폼 팩터 | SMARC2.0 & SMARC2.1 Compliance | SMARC2.0 & SMARC2.1 Compliance | SMARC2.0 & SMARC2.1 Compliance | SMARC2.0 & SMARC2.1 Compliance | SMARC2.0 & SMARC2.1 Compliance | SMARC2.0 & SMARC2.1 Compliance | SMARC2.0 & SMARC2.1 Compliance |
프로세서 | 중앙처리장치 | Intel Atom® x7-E3950 Processor | Intel Atom® x7-E3950 Processor | Intel Atom® x7-E3950 Processor | Intel Atom® x5-E3940 Processor | Intel Atom® x5-E3930 Processor | Intel Pentium N4200 | Intel Celeron N3350 |
주파수 | 1.6 GHz | 1.6 GHz | 1.6 GHz | 1.6 GHz | 1.3 GHz | 1.1 GHz | 1.1 GHz | |
최대 터보 주파수 | 2 GHz | 2 GHz | 2 GHz | 1.8 GHz | 1.8 GHz | 2.50 GHz | 2.40 GHz | |
코어 넘버 | 4 | 4 | 4 | 4 | 2 | 4 | 2 | |
LLC | 2MB | 2MB | 2MB | 2MB | 2MB | 2MB | 2MB | |
바이오스 | AMI UEFI BIOS at 64 Mb | AMI UEFI BIOS at 64 Mb | AMI UEFI BIOS at 64 Mb | AMI UEFI BIOS at 64 Mb | AMI UEFI BIOS at 64 Mb | AMI UEFI BIOS at 64 Mb | AMI UEFI BIOS at 64 Mb | |
메모리 | 테크놀로지 | Onboard LPDDR4-2400 | Onboard LPDDR4-2400 | Onboard LPDDR4-2400 | Onboard LPDDR4-2400 | Onboard LPDDR4-2400 | Onboard LPDDR4-2400 | Onboard LPDDR4-2400 |
ECC 지원 | No | No | No | No | No | No | No | |
맥스.용량 | 8GB | 4GB | 4GB | 4GB | 4GB | 8GB | 4 GB | |
채널/소켓 | Dual Channel / On Board Memory | Dual Channel / On Board Memory | Dual Channel / On Board Memory | Dual Channel / On Board Memory | Dual Channel / On Board Memory | Dual Channel / On Board Memory | Dual Channel / On Board Memory | |
그래픽스 | 컨트롤러 | Intel® HD Graphics 505 | Intel® HD Graphics 505 | Intel® HD Graphics 505 | Intel® HD Graphics 500 | Intel® HD Graphics 500 | Intel® HD Graphics 505 | Intel® HD Graphics 500 |
맥스.주파수 | 650MHz | 650MHz | 650MHz | 600 MHz | 550MHz | 750MHz | 650MHz | |
그래픽 메모리 | Intel DVMT5.0 | Intel DVMT5.0 | Intel DVMT5.0 | Intel DVMT5.0 | Intel DVMT5.0 | Intel DVMT5.0 | Intel DVMT5.0 | |
디스플레이 | LVDS | 2 channels 18/24-bit, up to 1920 x 1200 @ 60Hz | 2 channels 18/24-bit, up to 1920 x 1200 @ 60Hz | 2 channels 18/24-bit, up to 1920 x 1200 @ 60Hz | 2 channels 18/24-bit, up to 1920 x 1200 @ 60Hz | 2 channels 18/24-bit, up to 1920 x 1200 @ 60Hz | 2 channels 18/24-bit, up to 1920 x 1200 @ 60Hz | 2 channels 18/24-bit, up to 1920 x 1200 @ 60Hz |
DP/HDMI | 1DP and HDMI | 1DP and HDMI | 1DP and HDMI | 1DP and HDMI | 1DP and HDMI | 1DP and HDMI | 1DP and HDMI | |
트리플 디스플레이 | Yes | Yes | Yes | Yes | Yes | Yes | Yes | |
확장 | PCle x1 | Up to 4 PCIe x1 | Up to 4 PCIe x1 | Up to 4 PCIe x1 | Up to 4 PCIe x1 | Up to 4 PCIe x1 | Up to 4 PCIe x1 | Up to 4 PCIe x1 |
시리얼 버스 | SMBus | Yes | Yes | Yes | Yes | Yes | Yes | Yes |
I2 C 버스 | Yes | Yes | Yes | Yes | Yes | Yes | Yes | |
입력/출력 | SATA | 1 | 1 | 1 | 1 | 1 | 1 | 1 |
USB3.0 | 2 | 2 | 2 | 2 | 2 | 2 | 2 | |
USB2.0 | 6 | 6 | 6 | 6 | 6 | 6 | 6 | |
GPIO | 12 | 12 | 12 | 12 | 12 | 12 | 12 | |
컴 포트 | 4 Ports | 4 Ports | 4 Ports | 4 Ports | 4 Ports | 4 Ports | 4 Ports | |
와이파이 모듈 | 와이파이/BT 모듈 | 1 Wifi / BT Module on Board | 1 Wifi / BT Module on Board | N/A | N/A | N/A | 1 Wifi / BT Module on Board | N/A |
파워 | 타입 | ATX: Vin, VSB; AT: Vin | ATX: Vin, VSB; AT: Vin | ATX: Vin, VSB; AT: Vin | ATX: Vin, VSB; AT: Vin | ATX: Vin, VSB; AT: Vin | ATX: Vin, VSB; AT: Vin | ATX: Vin, VSB; AT: Vin |
전원 공급 장치 전압 | Vin: 4.75-5.25V, RTC Battery: 2.0V ~ 3.3V | Vin: 4.75-5.25V, RTC Battery: 2.0V ~ 3.3V | Vin: 4.75-5.25V, RTC Battery: 2.0V ~ 3.3V | Vin: 4.75-5.25V, RTC Battery: 2.0V ~ 3.3V | Vin: 4.75-5.25V, RTC Battery: 2.0V ~ 3.3V | Vin: 4.75-5.25V, RTC Battery: 2.0V ~ 3.3V | Vin: 4.75-5.25V, RTC Battery: 2.0V ~ 3.3V | |
환경 | 작동 온도 | 0 ~ 60° C (32 ~ 140° F) | 0 ~ 60° C (32 ~ 140° F) | 0 ~ 60° C (32 ~ 140° F) | 0 ~ 60° C (32 ~ 140° F) | 0 ~ 60° C (32 ~ 140° F) | 0 ~ 60° C (32 ~ 140° F) | 0 ~ 60° C (32 ~ 140° F) |
보관 온도 | -40 ~ 85° C (-40~185° F) | -40 ~ 85° C (-40~185° F) | -40 ~ 85° C (-40~185° F) | -40 ~ 85° C (-40~185° F) | -40 ~ 85° C (-40~185° F) | -40 ~ 85° C (-40~185° F) | -40 ~ 85° C (-40~185° F) | |
상대 습도 | 40° C @ 95%, Non-Condensing, operating; 60° C @ 95%, Non-Condensing, non-operating | 40° C @ 95%, Non-Condensing, operating; 60° C @ 95%, Non-Condensing, non-operating | 40° C @ 95%, Non-Condensing, operating; 60° C @ 95%, Non-Condensing, non-operating | 40° C @ 95%, Non-Condensing, operating; 60° C @ 95%, Non-Condensing, non-operating | 40° C @ 95%, Non-Condensing, operating; 60° C @ 95%, Non-Condensing, non-operating | 40° C @ 95%, Non-Condensing, operating; 60° C @ 95%, Non-Condensing, non-operating | 40° C @ 95%, Non-Condensing, operating; 60° C @ 95%, Non-Condensing, non-operating | |
기계식 | 치수 | 82 mm x 50 mm | 82 mm x 50 mm | 82 mm x 50 mm | 82 mm x 50 mm | 82 mm x 50 mm | 82 mm x 50 mm | 82 mm x 50 mm |
