<모바일 이용시 좌우로 슬라이드해서 보세요>
| General | | Graphics | ||||||||
| | | |||||||||
| ● Enclosure | - | ● Controller | Intel® HD Graphics 630, supports DirectX 12 | |||||||
| ● Dimension (W x H x D) | 77 x 192 x 230 mm (3.07" x 7.55" x 9.05") | ● VRAM | - | |||||||
| ● Mounting | Desktop/wall mount | ● VGA | - | |||||||
| ● OS Support | Windows 10 Pro | ● Display Port | - | |||||||
| ● Power Requirements | Typical: 32.1W , Maximum: 116W | ● Dual Display | - | |||||||
| ● Weight (Net) | 2.8 kg (6.17 lbs) | | ||||||||
| | | |||||||||
| | | |||||||||
| System Hardware | Environment | |||||||||
| | | |||||||||
| ● CPU | intel I7-9700TE | ● Operation Temperature | -10 ~ 50 °C (w/ industrial wide-temp SSD, 0.7m/s air flow) | |||||||
| ● Chipset | H310 chipset | ● Storage Temperature | - | |||||||
| ● Memory | DDR4 16G | ● Humidity (storage) | 95% @ 40 °C (non-condensing) | |||||||
| ● Ethernet | 2 x GigaLAN | ● Vibration | - | |||||||
| ● Storage | SSD 500G | | ||||||||
| ● I/Os | USB : 4 x USB 3.0 and 4 x USB 2.0 Serial Port : 2 x DB9, 2 x RS-232/422/485 support auto flow control; 4 x RS-232 (Optional) Audio : 2 (1 x line out and 1 x mic in) | | ||||||||
| ● Expansion | - | | ||||||||
<모바일 이용시 좌우로 슬라이드해서 보세요>
| General | | Graphics | ||||||||
| | | |||||||||
| ● Enclosure | - | ● Controller | Intel® HD Graphics 630, supports DirectX 12 | |||||||
| ● Dimension (W x H x D) | 77 x 192 x 230 mm (3.07" x 7.55" x 9.05") | ● VRAM | - | |||||||
| ● Mounting | Desktop/wall mount | ● VGA | - | |||||||
| ● OS Support | Windows 10 Pro | ● Display Port | - | |||||||
| ● Power Requirements | Typical: 32.1W , Maximum: 116W | ● Dual Display | - | |||||||
| ● Weight (Net) | 2.8 kg (6.17 lbs) | | ||||||||
| | | |||||||||
| | | |||||||||
| System Hardware | Environment | |||||||||
| | | |||||||||
| ● CPU | intel I7-9700TE | ● Operation Temperature | -10 ~ 50 °C (w/ industrial wide-temp SSD, 0.7m/s air flow) | |||||||
| ● Chipset | H310 chipset | ● Storage Temperature | - | |||||||
| ● Memory | DDR4 16G | ● Humidity (storage) | 95% @ 40 °C (non-condensing) | |||||||
| ● Ethernet | 2 x GigaLAN | ● Vibration | - | |||||||
| ● Storage | SSD 500G | | ||||||||
| ● I/Os | USB : 4 x USB 3.0 and 4 x USB 2.0 Serial Port : 2 x DB9, 2 x RS-232/422/485 support auto flow control; 4 x RS-232 (Optional) Audio : 2 (1 x line out and 1 x mic in) | | ||||||||
| ● Expansion | - | | ||||||||
