<모바일 이용시 좌우로 슬라이드해서 보세요>
| General | | Graphics | ||||||||
| | | |||||||||
| ● Enclosure | Aluminum Housing | ● Controller | Integrated Intel® HD Graphics 530 / 630 | |||||||
| ● Dimension (W x H x D) | 214 x 200 x 73 ( Exclude Brace ) | ● VRAM | Shared system memory, 2 GB and above | |||||||
| ● Mounting | Embedded, Desktop or Wallmount | ● VGA | Max. resolution 1920 x 1200 @ 60Hz | |||||||
| ● OS Support | Win10 IoT 64bit | ● Display Port | Max. resolution 4096 x 2160 @ 60Hz | |||||||
| ● Power Requirements | DC12V, 100W | ● Dual Display | VGA + DP | |||||||
| ● Weight (Net) | 2.9Kg | | ||||||||
| | | |||||||||
| | | |||||||||
| System Hardware | Environment | |||||||||
| | | |||||||||
| ● CPU | Intel® CoreTM I / Pentium / Celeron | ● Operation Temperature | 0~50℃ | |||||||
| ● Chipset | H110 | ● Storage Temperature | -20℃~60℃ | |||||||
| ● Memory | Up to 16 GB DDR4 SO-DIMM | ● Humidity (storage) | 8~85% non condensing | |||||||
| ● Ethernet | Dual Gigabit Ethernet | ● Vibration | 10~200 Hz, P-P, 1.0 Grms 30 mins/axis (Non Operating) | |||||||
| ● Storage | 1 x mSATA SSD interface | | ||||||||
| ● I/Os | 2 x RS232 4 x USB 3.0 VGA, DP Port Line-out, Mic | | ||||||||
| ● Expansion | - | | ||||||||
<모바일 이용시 좌우로 슬라이드해서 보세요>
| General | | Graphics | ||||||||
| | | |||||||||
| ● Enclosure | Aluminum Housing | ● Controller | Integrated Intel® HD Graphics 530 / 630 | |||||||
| ● Dimension (W x H x D) | 214 x 200 x 73 ( Exclude Brace ) | ● VRAM | Shared system memory, 2 GB and above | |||||||
| ● Mounting | Embedded, Desktop or Wallmount | ● VGA | Max. resolution 1920 x 1200 @ 60Hz | |||||||
| ● OS Support | Win10 IoT 64bit | ● Display Port | Max. resolution 4096 x 2160 @ 60Hz | |||||||
| ● Power Requirements | DC12V, 100W | ● Dual Display | VGA + DP | |||||||
| ● Weight (Net) | 2.9Kg | | ||||||||
| | | |||||||||
| | | |||||||||
| System Hardware | Environment | |||||||||
| | | |||||||||
| ● CPU | Intel® CoreTM I / Pentium / Celeron | ● Operation Temperature | 0~50℃ | |||||||
| ● Chipset | H110 | ● Storage Temperature | -20℃~60℃ | |||||||
| ● Memory | Up to 16 GB DDR4 SO-DIMM | ● Humidity (storage) | 8~85% non condensing | |||||||
| ● Ethernet | Dual Gigabit Ethernet | ● Vibration | 10~200 Hz, P-P, 1.0 Grms 30 mins/axis (Non Operating) | |||||||
| ● Storage | 1 x mSATA SSD interface | | ||||||||
| ● I/Os | 2 x RS232 4 x USB 3.0 VGA, DP Port Line-out, Mic | | ||||||||
| ● Expansion | - | | ||||||||
