| General | | LCD Display | ||||||||
| | | |||||||||
| ● Bios | In Conformity with CPU | ● Display Type | XGA TFT LCD | |||||||
| ● Certification | - | ● Display Size | 12.1" | |||||||
| ● Dimension (W x H x D) | 341 x 261 x 72 | ● Max. Resolution | 1024 x 768 | |||||||
| ● Panel Cut-out Dimension | - | ● Max. Color | 262K | |||||||
| ● Power Input | 40W ± 5% | ● Luminance | 500@120mA | |||||||
| ● Weight | 3.8Kg | ● Contrast Ratio | 700:1 | |||||||
| | | |||||||||
| | | |||||||||
| System Hardware | Touch Screen (optional) | |||||||||
| | | |||||||||
| ● CPU | Intel® AtomTM, CeleronTM, CoreTM i | ● Type | 5-wire Resistive | |||||||
| ● Chipset | In Conformity with CPU | ● Interface | USB | |||||||
| ● Memory | Up to 8 GB DDR3/DDR3L SODIMM | ● Touch Resolution | - | |||||||
| ● I/Os | 2 x RS232 5 x USB 2.0 (one at front) 2 x PS2 (Keyboard, Mouse) 1 x VGA Port, 1 x HDMI Port Mic-in, Line-in, Line-out | | ||||||||
| ● Expansion (optional) | 1 x half-length PCI Slot 1 x Mini PCIe (Full-size) | | ||||||||
| | Environment | |||||||||
| | ||||||||||
| ● Operation Temperature | 0~50℃ | |||||||||
| ● Humidity (storage) | 8~85% non condensing | |||||||||
| ● Vibration | 10~200 Hz, P-P, 1.0 Grms 30 mins/axis (Non Operating) | |||||||||
